New, never used or installed. Open box, original packaging is worn. Brand
LEVITON
Manufacturer Part Number
T5020-W
Receptacle Type
Single
NEMA Receptacle Configuration
5-20R
Current Rating
20 A
Voltage Rating
125V AC
Phase
Single
GFCI
No
Grounding
Grounded
Wire Connection Types
Screw Terminals
Wire Connection Location
Back; Side
Connection Orientation
Straight
Number of Poles
2
Number of Wires
3
Resistance Properties
Tamper Resistant
Additional Electrical Protections
Standard Protection
Contact Material
Brass
Cover Type
No Cover
Face Plate Height
2.38 in
Face Plate Width
1.31 in
Horsepower Rating
1 hp
Housing Color
White
Housing Material
Thermoplastic Nylon
Includes Mounting Hardware
Yes
Maximum Operating Temperature
60 °C
Maximum Wire Size
10 AWG
Minimum Operating Temperature
-40 °C
Minimum Wire Size
14 AWG
Mount Hole Center-to-Center Height
3.28 in
Mount Type
Flush
NEMA Enclosure Rating
Not Rated
Number of Outlets
1
Overall Depth
1.06 in
Polarized
Yes
Standards
ANSI; CSA Certified; UL Listed
Wire Connection Type
Screw Terminals
